MOULDER VK-B623D-AR

MOULDER VK-B623D-AR

• CLICK HERE TO DOWNLOAD PDF FILE
• Working Width: 25-230mm
• Working Thickness: 08-160mm
• Min Working Length: 580-300mm.
• Blade Diameter: 40mm
• Feeding Speed: 5-40m/min
• Main Spindle Speed: 7000rpm/min
• Trimming Blade Diameter: 145-150mm
• 1^st Lower Blade Diameter: 125mm
• Left/Ride Blade Diameter: 110-160mm.
• 1^st Upper Blade Diameter: 125-160mm
• 2^nd Second Blade Diameter: 125-160mm
• 2^nd Lower Blade Diameter: 125-180mm
• Total Motor Power: 54.75kw
• 1^st Lower Blade Power: 4kw
• Left/Ride Blade Power: 5.5kw
• 1^st Upper Blade Power: 7.5kw
• Left/Ride Blade Power: 7.5kw
• 1^st Upper Blade Power: 11kw
• 2^nd Upper Blade Power: 7.5kw
• 2^nd Lower Blade Diameter: 7.5kw
• Feeding Motor Power: 5.5kw
• Lifting Motor Power: 1.5kw
• Pneumatic Source Pressure: 0.6Mpa
• Dust Outlet Diameter: 6*150mm
• Overall Size (with cover): 3680*1700*1860mm
• Overall Size (no cover): 3620*1420*1840mm
• Weight: 4000kg
