19. 6 SPECIAL HANDLE EDGE BANDER MACHINE J+C+SEMI J + 45

J+C+SEMI J + 45

• CLICK HERE TO DOWNLOAD PDF FILE
• Material requirements: Plate thickness: 18mm: Customizable 22mm\25mm)
• Material requirements: Sealing plate size: ≥250*120mm: 250 It is the size of the edge banding direction.
• Material requirements: Thickness of edge banding: 0.52-0.56mm
• Material requirements: Edge banding width: J type 54mm   C type 33mm
• Material requirements: Type of edge banding: PVC Matte surface effect is better.
• Material requirements: Hot melt adhesive type: PUR, EVA
• Equipment parameters: Supply voltage: 380V/50HZ
• Equipment parameters: Total Power of equipment: 42KW
• Equipment parameters: Air pressure: 0.6-0.8Mpa
• Equipment parameters: Feed speed: 12/min

• Equipment parameters: Operating temperature of glue pot: 110℃-210℃
• Equipment size: 882*107*185cm
• Product weight: 3200kg
• Total power: 47.1kw
• Power supply voltage: 380v/three-phase five-wire/50HZ
• Edge banding strip width J-shaped half-pass J: 58mm-60mm; C; 36mm X; 28mm
• Hot air blower: 3.3kw
• Blower: 0.15kw
• Air source pressure: 0.6mpa-0.8mpa
• Type of edge banding: PVC
• Baking lamp heating: 1.5kw*2
• External vacuum port: Φ100mm
• Thickness of edge banding strip: usually 0.5-0.6mm (related to edge banding strip)
• Simultaneous motor: 380V 0.37kw*2
• Touch screen Xianjie: 15-inch industrial touch screen.
• J type adjustment motor: 0.4kw*2
• Rough repair of motor: 380V 0.75kw*2
• Frequency converter Xianjie: Industrial grade frequency converter
• Conveyor motor: 380V 4kw
• The minimum size of the middle handle: 13 cm, there is no maximum limit.
• Polishing motor: 380V 0.37kw*4
• PLC: Xianjie
• Lift motor: 380V 0.37kw
• Plate width: ≥100mm.
• Electronic control components: Chant
• Pre-milling motor: 3.7KW*2
• Semi-J type/mid-position motor: 7.5KW*2
• Inclined straight milling motor: 4.0KW
• Plate length: ≥250mm.
• Edge banding speed: 0-12m/min (variable speed)
• Thickness of edge banding plate: 18-25mm (JC)
• Glue pot capacity: 1500g*2.
• Glue pot heating: 2kw.
• Press heating power: 0.3kw
• Glue pot operating temperature: 150-170℃
• Edge banding motor: 380v 0.37kw
• Fine repair motor: 0.75kw
• Slotting motor: 220V 0.8kw
• The distance between delivery boards: 1.5m-1.8m
